Product Description
Timco Multi-Fix Hex Head Bolts are micro-plated (Nano) brass nuts designed to replace traditional expansion anchors. The unique concave thread configuration enables the nut to be easily inserted into a hole and offers high pull-out values. The nuts can be removed for future use or adjustment, even after installation. They conform to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials that are unlikely to collapse prematurely in the event of a fire.
- Designed to replace traditional expansion anchors
- TIMco micro plating (Nano) technology gives a higher resistance to corrosion
- High-Low parallel threads for ease of insertion and high pull-out values
- Removable adjustable non-expansion through fixing
- Unique concave thread configuration
- All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring
- systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire
Specification
- Size Ø x L mm
- 10.0 x 100
- Drill Hole Ø mm
- 10
- Fixture Hole Size Ø mm
- 12
- Socket Size mm
- 17
- MFT mm
- 50
- Finish
- Exterior Silver Organic
- Head Type
- Hex
- Thread Type
- High-Low Parallel
- Point Type
- Chamfered
- Corrosion Rating 1-5
- 3 - Urban & industrial areas with a low salt atmosphere
- Salt Spray Resistance Hrs Tested to BS EN 9227
- 400
- Substrates
- Wood, Concrete, Brick, Block, Stone
- MOQ
- 1
- MOQ Increment
- 1
+ Delivery & Returns
Timco Multi-Fix Hex Head Bolt
£14.32Each
