Fakro Manual Conservation Center Pivot PTP PVC Roof Window

SKU: BW-39448 MFC: 87BM01

Variations & Sizes

  1. Step 1
  2. Select Window Size: Width x Length
  1. Step 2
  2. Select Flashing
For Compatible Blinds Click Here

Product Description

Fakro Center-pivot Conservation Roof Windows is ideal for use with historic or stylised properties. This product is available for added ventilation and light with a design made especially for traditional construction. It is characterised by black vertical mullion bar in the middle of the glazing, cladding and flashing. Apart from providing aesthetics, they allow light and air as well. It features everything else you expect from a high quality roof window.

  • Available in Different Sizes
  • Traditional centre pivot operation
  • Well equipped window version with hinges located in the middle of the window height
  • Turn through 180Deg to clean outer pane within the room
  • Operating handle in the base of the sash for ease of use
  • Suitable for retro-fitting of electronic operation
  • Compatible for pitches from 15-90Deg
  • Window with a mullion bar is designed for historic or stylised buildings.
  • Characteristic feature is black vertical mullion bar in the middle of the glazing, cladding and flashing
  • Suits traditional construction
  • Keeps the unique, historic character of the building from the outside and create a comfortable and modern interior
+ Delivery & Returns

Fakro Manual Conservation Center Pivot PTP PVC Roof Window

£368.02Each
Fakro Manual Conservation Center Pivot PTP PVC Roof Window
  • Finish - PVC
  • PVC profile with steel reinforcement for a smooth, wipe clean finish
  • V35 air inlet
  • Glazing - P2 - Safety Double Glaze
  • Single chamber glazing
  • Laminated and anti-burglary class P2A according to standard EN 356
  • Increased resistance against breakage
  • Consists of external toughened pane with easy maintenance layer
  • Warm TGI spacer and inner pane has two 3mm thick sheets of glass with 0.76mm layer of PVB plastic membrane between them
  • Glazing cavity is filled with inert gas- argon
  • On the inner side of the laminated glass it has a low emission coating which reduces penetration of UV rays by up to 99 Percent
  • Flashing - EZV-A
  • For interlocking tiles up to 45mm profile.
  • Ideal for fitting windows with profiled roof coverings such as roof tiles and metal sheeting.
  • Universal flashing which can be applied not only to corrugated coverings and roof coverings with a profile depth of up to 45mm
  • Applied to individual windows in the slope of the roof
  • Used as flashing for windows used in group for V depths in horizontal, vertical, and block
  • Roofs with pitches from 15Deg to 90Deg for depths V
  • Depths in the roof construction V - (0cm)
  • Flashing - EZJ-A - Recessed Style
  • For interlocking tiles up to 45mm profile
  • Ideal for fitting windows with profiled roof coverings such as roof tiles and metal sheeting.
  • Universal flashing which can be applied not only to corrugated coverings and roof coverings with a profile depth of up to 45mm
  • Applied to individual windows in the slope of the roof
  • Used as flashing for windows used in combinations for depth J in horizontal
  • Roofs with pitches from 20Deg to 90Deg for depths J
  • Depths in the roof construction J - (–3cm)
  • Flashing - ELV
  • For non-interlocking slate up to 10mm thick.
  • ideal for fitting windows within slated roofs coverings up to 10mm thickness.
  • Applied as standard to individual windows in the slope of the roof.
  • window units combined for V depth in vertical, horizontal and block groups
  • Roofs with pitches from 15Deg to 90Deg for depths V
  • Depths in the roof construction V - (0cm)
  • Flashing - ELJ - Recessed Style
  • For non-interlocking slate up to 10mm thick.
  • ideal for fitting windows within slated roofs coverings up to 10mm thickness
  • Applied as standard to individual windows in the slope of the roof
  • window units combined for J depth horizontal only
  • Roofs with pitches from 20Deg to 90Deg for depths J
  • Depths in the roof construction J - (–3cm)
  • Flashing - EPV
  • For plain tiles up to 16mm thick.
  • Ideal for a fit between windows and heavy tiled roof coverings such as plain tiles, shingles.
  • Applied to roof coverings of up to 24 – 32 mm thickness.
  • For individual windows in the slope of the roof.
  • Window units may also be combined in horizontal, vertical and block groups.
  • Roofs with pitches from 25Deg to 90Deg for depths V
  • Depths in the roof construction V - (0cm).
  • Flashing - EPJ - Recessed Style
  • For plain tiles up to 16mm thick.
  • Ideal for a fit between windows and heavy tiled roof coverings such as plain tiles, shingles.
  • Applied to roof coverings of up to 24 – 32 mm thickness.
  • For individual windows in the slope of the roof.
  • Window units may also be combined in horizontal, vertical and block groups.
  • Roofs with pitches from 30Deg to 90Deg for depths V
  • Depths in the roof construction J - (-3cm).
  • Flashing - EHN-A
  • For interlocking tiles up to 90mm profile.
  • Suitable for the water tight connection of roof windows with roof coverings such as roof tiles and high profile metal sheeting
  • Applied to roof coverings with a profile depth of up to 90 mm and is applied to individual windows in the slope of the roof.
  • Used as module flashing for windows installed in horizontal and vetrtical combinations or block groups.
  • The flashing is available for one installation depth, allowing installation of windows at a level N (+3)
  • Can be used on roofs with pitches between 15Deg and 90Deg
