Product Description
Brett Martin Glass Link Rooflight - Fixed is a thermally efficient product with a thermally broken frame and units glazed with Low-E insulated double-glazed glass units. Made for fast and secure installation on flat roofs of all modern buildings to allow the easy flow of natural light and ventilation, this rooflight can be purchased in a number of different sizes. It is compatible with roof pitches ranging from 2 degrees - 35 degrees, satisfying different applications. This product comes in a factory-assembled glass body for durable use and offers extreme versatility.
- Fixed Glass Link Rooflight
- Fast and simple installation thanks to large modules and no additional flashings - modules simply lap together and side-fix
- Guaranteed weather tightness with factory-glazed modules requiring no on-site glazing sealant
- Suitable for pitches of 2 degrees - 35 degrees providing a versatile solution for a variety of applications
- Elegant aluminium framework powder coated to fashionable anthracite grey RAL 7016 outside and white RAL 9010 inside
- Highly thermally efficient with thermally broken frame and units glazed with Low-E insulated double-glazed glass units
- Safety of those below and above the roof light assured thanks to a laminated inner pane and the product achieving non-fragility to CWCT TN-67 (for class 2 roofs) and Class B non-fragile to ACR[M]001 when new and fully installed to Brett Martin installation guidelines
- Highly secured by design opens in new window accreditation
- 10-year commercial product warranty
- BBA approved
- Design Features:
- Premium quality factory-assembled glass roof light units
- Modules are constructed from structurally glazed double-glazed units in a powder-coated, fully thermally broken aluminium frame
- All modules are flush, providing a seamless aesthetic
- Components of powered opening roof lights are completely concealed for an unobstructed light well
- Dual colour powder coated as standard, fully thermally broken aluminium framework
- Spans of up to 3800mm are possible with individual modules of up to 3800x1750mm allowing for large uninterrupted
- daylight areas
- Fixed Brett Martin Glass Link roof lights achieve Secured by Design accreditation
- Sleek and contemporary design
- Ideal for both residential and commercial applications
- Product Options Summary:
- Multipane Modules
- Large modules can be glazed with multiple panes of glass to avoid the need for heavier and more expensive glass specifications
- Glazing Specification:
- Standard specification
- 6mm toughened outer - 16mm Argon spacer
- 9.5mm laminate with 1.5mm PVB interlayer (for very large sizes inner pane increases to 11.5mm)
- CWCT TN-67 for class 2 roofs
- ACR[M]001 Class B non-fragile
Specification
Brett Martin Glass Link Rooflight - Fixed
RRP: £2535.98
Save 50%
£1267.99
